RK Rose+Krieger (part of the international Phoenix Mecano group of companies) have been manufacturing components for automation and machine building for over 40 years. Our extensive range of products in the fields of linear adjustment, profile technology, connecting and module technology are renowned and respected for their reliability and performance.
As a company we are always striving to look for new ways to advance our products. For example, we have recently expanded our range of monitor mounting components even further.
NEW : RK monitor mounting compact
RK Rose+Krieger now supplies its tried-and-tested RK monitor mounting for operating terminals, monitors and other display devices with a short construction length as the “compact” version. The new mounting is 50 mm shorter than the respective standard mounting and can be used flexibly and universally wherever there is restricted available space. The connection for the display devices is established using a universal plate or VESA mount. The end user has the choice between VESA 50/75 (new) and VESA 75/100. Thanks to the ball joint on the device connection the RK compact monitor holder provides a great degree of freedom. The variable fixing principle with half shells and reducing inserts for round and square tubes allows installation on profiles and tubes with edge lengths or diameters of 20, 25 or 30 mm.
Click here for further information
Monitor mountings for industrial applications
The monitor mounting from RK Rose+Krieger is a high-strength and flexibly mountable solution for the fixing and ergonomic adjustment of monitors and touch panels in industrial adjustments. The vibration-proof and lockable version with tilt adjustment in 15° increments is suitable for monitors, control panels and touch panels up to 25 kg (static) and offers a wide range of adjustment options: for example, it allows the screen to be turned, tilted and swivelled and – if fixed to a round or square tube system – height-adjusted without tools. The new version of the RK monitor mounting with ball joint offers even greater flexibility for the adjustment of industrial monitors. The joint enables a pivoting range of 60° with a load of up to max. 10 kg (static). A special coating on the ball joint and a clamping mechanism that is registered as a utility model guarantee the static friction required for reliable processes when the clamping lever is tightened.
Monitor mounting, with a choice of universal or VESA mount
With different fitting dimensions for end devices and a choice of mounting options, the RK monitor mounting offers maximum flexibility: users can choose between a cross-shaped connecting plate as per VESA Standard 75/100 – i.e. with a 75 x 75 mm or 100 x 100 mm mounting hole pattern – or a round aluminium universal mounting surface. The monitor mounting is compatible with RK connecting technology and the BLOCAN® aluminium profile system, although it can also be mounted on any other tube or profile or directly wall-mounted. The screws and slot stones required for fixing to an RK profile system are included in the scope of delivery.
Tablet holder and support arm expands range of RK monitor mounting accessories
The monitor mountings from RK Rose+Krieger allow for an optimal view of the monitor or a control panel. The range of action can be increased even further by using a support arm. Two different support arms/swivel arms are available, based on the load to be supported (monitor weight, torque support). The basic version has one support tube for loads of up to 10 kg , and the twin version has two support tubes for loads of up to 25 kg.
In addition to the support arm, the new tablet holder has further extended our accessories range. This holder enables the quick and easy fastening of tablet PCs and other flat display devices to the monitor mounting.
Advantages of the RK monitor mounting at a glance:
- Choice of user-specific or VESA-standard monitor connection
- High-strength materials ensure a long-term load-bearing capacity of up to 25 kg (static), for reliable processes, in the case of ball joint version up to 10 kg (static)
- Highly ergonomic thanks to personalised height adjustment
- Optimum adjustment of the field of vision thanks to side-turning
- Vibration-proof locking in 15° increments or 60° pivoting range (in the case of ball joint version)
- Pivoting option enables portrait or landscape monitor format
- Connects to aluminium profile and thus also to the machine frame using slot stones
- Universal mounting holes facilitate simple wall mounting
